SCS-315P

Sealed Cardioid Sub-Bass

The SCS-315P is a self-powered cardioid sub-bass loudspeaker, designed to match the superb transient response of a CLA or HLA Hybrid Line Array. It extends system low frequency response, projection and directional control to 38 Hz. Three 15-inch long-excursion drivers are employed in a cardioid configuration using on-board Powersoft DSP and amplification. The drivers have (.7Q) sealed enclosures for optimum transient response.

Key Features

• Cardioid Pattern Control to 38HZ
• Precise Bass Transient Response
• 4500 Watts of Powersoft Class D Power

Applications

• Compact Flown Sub-bass
• Ground-Stacked Sub-Bass With Reduced On-Stage Bleed
• Bass-Projection to Match Line Array Behavior

Nominal Data

Frequency Response 38 Hz-–140 Hz ±3dB
Components & Loading (3) 12" LF drivers in separated enclosures
Maximum Long Term Output 127 dB
Peak Output 133 dB
Power Handling 4500W RMS
Front-To-Back Ratio 12 dB
Height 38.00" [965mm]
Width 21.13" [537mm]
Depth 27.63" [702mm]
Net Weight 114 lbs [51.7kg]
Shipping Weight 122 lbs [56.5kg]
