INNOVOX AUDIO LOUDSPEAKER SUB WOOFER

DLFC-308

The DLFC-308 is a dipole, cardioid-configured loudspeaker purpose-built to enhance the mid-bass performance of CLA Series Line Arrays in biamplified or triamplified system configurations. It features three 8” drivers, each housed in a separate sealed enclosure—two front-facing and one rear-facing. The front-facing drivers are precisely spaced to generate a dipole cancellation effect between 150 Hz and 325 Hz, delivering extended vertical pattern control and enhanced intelligibility. The rear-facing driver provides cardioid behavior, minimizing low-frequency radiation behind the enclosure. Below 150 Hz, the DLFC-308 operates as a conventional low-frequency system, delivering powerful and clear low-end support. Each driver is independently terminated, allowing for individual delay and level adjustments. This enables vertical beam steering—either upward or downward—tailored for acoustically reflective or architecturally sensitive spaces.

INNOVOX AUDIO LOUDSPEAKER SUB WOOFER

DLFC-608

The DLFC-608 is a dipole, cardioid-configured loudspeaker purpose-built to enhance the mid-bass performance of CLA Series Line Arrays in biamplified or triamplified system configurations. It features six 8” drivers, each housed in a separate sealed enclosure—four front-facing and two rear-facing. The front-facing drivers are precisely spaced to generate a dipole cancellation effect between 150 Hz and 325 Hz, delivering extended vertical pattern control and enhanced intelligibility. The rear-facing drivers provide cardioid behavior, minimizing low-frequency radiation behind the enclosure. Below 150 Hz, the DLFC-308 operates as a conventional low-frequency system, delivering powerful and clear low-end support. Each driver is independently terminated, allowing for individual delay and level adjustments. This enables vertical beam steering—either upward or downward—tailored for acoustically reflective or architecturally sensitive spaces.
